PRODUCT DESCRIPTION
The Kraft&Dele KD11404 universal meter is made of solid materials, guaranteeing high durability of the device, both against mechanical damage and unfavorable weather conditions.
Suitable for both professional and home use, its compact size ensures easy portability. Its advantages include an LCD display and an additional data logging function.
The new, unique technology used in the production of this device has allowed us to achieve an excellent product from the exclusive Kraft&Dele brand for the most demanding users.
APPLICATION:
Direct current (DC) measurements
Alternating voltage (AC) measurements
Direct current (DC) measurements
Resistance measurement
Transistor hFE tests
Diode forward voltage measurements
Short circuit test - numerical + sound
General specifications:
Display: 3-digit LCD display with maximum reading 1999
Measurement speed: update 2-3 / sec.
Overrange indication: only the number "1" on the display
Automatic indication of negative polarity.
The "" symbol is displayed when the battery voltage drops below the operating voltage.
Full range over load protection.
Capacitance measurement Automatic zeroing.
Auto Power Off: It will automatically shut off approximately 15 minutes after power is turned on. To continue powering on, you must turn it off and then on again.
Operating temperature: 0°C~40°C, 0~75%RH
Storage temperature: -10°C~50°C, 0~75%RH
Power Supply: Single standard 9V IEC 6F22, NEDA 1604, JIS 006P battery.
Dimensions: 191L ​​* 89W * 35Hmm.
Weight: approx. 310g (including battery)
Accessories: test leads (pair), 2x batteries, user manual.
Safety Compliance: IEC 61010-1, 2000 CAT I 1000 V overvoltage standards.
Overvoltage installation categories according to IEC 61010-1, 2000: The meter is designed to protect against transients in the following categories:
CAT I From high voltage low voltage sources, e.g. electronic circuits or photocopiers.
CAT II From equipment supplied from a stationary installation, e.g. TVs, PCs, portable tools and household appliances.
CAT III From equipment in fixed equipment installations, e.g. installation panels, power supplies and short branch circuits and lighting systems in large buildings.

PRODUCT TECHNICAL PARAMETERS


Model: KD11404
Display: LCD
Max display reading : 1999
Acoustic signaling : YES
Read memory : YES
Operating temperature : 0°C - 40°C
Power supply: 2x battery (R03P)
Model: DT8205A
