Installation included

NEW!!! R32 Gas (Refrigerant)

Up to 4 metres Copper Piping

5 Years Full Guarantee



COOLING . A++ / HEATING A+++



Indoor Unit Size (W x D x H) : 80.5 x 19.4 x 28.5 CMS

Outdoor Unit Size (W x D x H): 72.0 x 27.0 x 49.5 CMS



Technical Specifications

Rated Capacity

Cooling

W

3500

Heating

W

3500

Dehumidifying

Kg / Hr

-

Rated Power Consumption

Cooling

W

1090

Heating

W

970

Rated Power Current

Cooling

A

4.8

Heating

A

4.3

Electric Heating Power

W

-

Maximum Input Power

W

1900

Maximum Input Current

A

9.5

EER Cooling

W / W

6.1

COP Heating

W / W

4.0

Power Supply Source

V / Ph / Hz

220 ~ 240V / 1 / 50Hz

Refrigerant



R32

Refrigerant Charged

gr

680

Maximum Discharge Pressure

Mpa

4.28

Maximum Suction Pressure

Mpa

1.15

Airflow Volume

m3 / Hr

600

Noise Level

dB (A)

52

Noise Level

dB (A)

58

Indoor Unit Weight (Net)

Kgs

8

Outdoor Unit Weight (Net)

Kgs

26
