DESCRIPTION
Engine Manufacturer Yanmar
Engine Model 4TNV86CHT
Aspiration Turbocharger
Displacement, ltr (Inches³) 2.1 (128)
Rated Speed, rpm 2600
SAE Net Power, kW (hp) 45.6 (61)
SAE Gross Power, kW (hp) 48.5 (65)
Max. Gross Torque, Nm (lbf / ft) 207 (153)
Tire size – Standard 10 – 16.5
DRIVELINE
Length – No Bucket, mm (inches) 2630 (103)
Length – With Bucket Foundry, mm (inches) 3240 (127.6)
Width – No Bucket, mm (inches) 1600 (62.9)
Overall Height, mm (inches) 1960 (77.2)
Ground Clearance, mm (inches) 180 (7)
Wheelbase, mm (inches) 1050 (41.5)
Rear Departure Angle, Degrees 22.3
Height to Hinge Pin, mm (inches) 2920 (115.1)
Dump Angle, Degrees 45
Dump Height – Maximum Foundry, mm (inches) 2250 (88.6)
Reach – Max Dump Height Foundry, mm (inches) 400 (15.8)
Rollback – Ground Level, Degrees 30
DIMENSIONS
Fuel Tank, ltr (gallons (US)) 71 (19)
CAPACITIES
Rated Operating Capacity – Foundry, kg (lbs) 795 (1750)
Tipping Load – Foundry, kg (lbs) 1589 (3500)
Speed – Maximum, kph (mph) 11.1 (6.9)
Breakout – Lift Foundry, kN (lbf) 21.1 (4750)
Breakout – Bucket Foundry, kN (lbf) 23.3 (5250)
Hydraulic Power, kW (hp) 24.729 (33.1)
Pump Output, lt/min (gallons (US) / min) 63 (17)
System Pressure, bar (PSI) 237.87 (3450)
PERFORMANCE
Operating Weight – Foundry, kg (lbs) 2806 (6180)
